CMM Software


WM | Quartis

WM | Quartis is a versatile, modern coordinate measuring machine software. WM | Quartis makes it easier to obtain meaningful measurement results. While many CMM software’s have evolved and grown to work in the Windows environment, Quartis is the first software to be designed using the trend-setting Microsoft® Office Fluent™ user interface. The result is a measuring software with an uncluttered, flexible and result-orientated workspace that reduces distraction for users so they can spend more time and energy focused on their work. Measurement results can now be generated even faster and easier.

WM | Quartis is a versatile, result oriented software suited for a wide variety of applications, such as aerospace, medical, interior/exterior automotive, consumer goods and precision components.

Features and Benefits of WM | Quartis

  • WM | Quartis works equally with all sensor types: touch probe, 3D scanning, optical and laser.
  • Complete machine and sensor simulation allows for an efficient offline programming and testing environment.
  • Path generators allow the user to easily and quickly program complex or repetitive measurement paths, regardless of the sensor type.
  • Built in SPC allows you to combine process control, with CAD visualization for rich, dynamic reports.



Functionally enhanced metrology equipment software allowing open access to CMM CAD performance for 3D scanning. A truly unique user interface. Dynamic function-sensitive toolbars, action icons and context-sensitive work areas characterize OpenDMIS 3D scanning software. The graphics window remains visible at all times, maximizing operating efficiency.

No pop-up windows to close, no cascading menus, no screen crowding and no annoying “drill down” functionality.

This next generation metrology equipment software for all new WENZEL coordinate measuring machines, software upgrades and retrofits minimizes the learning curve, for a rapid progression of the new user to full-feature capability.

For the first time, CMM software is intuitive, powerful, and easy to use. No function is more than one mouse click away. No other software can claim the one click performance and drag-and-drop functionality of OpenDMIS 3D scanning software.

Feature and Benefits of OpenDMIS

  • CAD capabilities: CAD model mirroring, solid model part and fixture representation and world coordinate translation.
  • Virtual programming: crash prediction and avoidance, online and offline programming modes and DMIS 5.0 compatibility.
  • Intelligent measurement: smart measure algorithms, auto probe to feature alignment and object based programming.
  • OpenDMIS reporting: Excel file output, HTML reports and traditional numerical ASCII reports.
  • Auto routines: grid points, 3D scanning and probe calibrations.
  • Scanning: analog Renishaw probe scanning, full REVO compatibility and data export in IGES B-spline.
  • Relative measurement: thin wall components, material thickness compensation and vector build macros.
  • Operations toolbar: easily use measurement, construction and sensor tools.
